Allen-Bradley 1756-IF16/A, ControlLogix 16 Point Analog Input/Output Module

Model Type:ControlLogix I/O Module

Model Number:1756-IF16/A

Manufacturer:Allen-Bradley

Input Type:Analog Input

Output Type:Analog Output

Channels:16

Current Rating:Drawn: 1.16 A at 5.1 VDC, 3.4 MA at 24 VDC

Enclosure:Open Type

Temperature Rating:32 – 140 DEG F

Environmental Conditions:5 – 95% non-condensing relative humidity

Vibration Resistance:2 G

Shock Resistance:30 G

Communication Speed:10/100 MBPS

Protocol:Ethernet/IP Bridge

Power Supply:3 MA at 24 VDC

Power Dissipation:5.1 W

Isolation:30 V continuous

Connection Cables:802.3 compliant shielded or unshielded twisted pair

    The AB ControlLogix IF16/A module is specifically engineered for seamless integration into the ControlLogix PLC system, ensuring reliable operation in demanding industrial environments.

    Featuring a wide range of signal types, it enables precise control over processes, from temperature monitoring to flow rate regulation, enhancing operational efficiency.

    With its robust design and high current consumption capability, the IF16/A module ensures stable performance even under extreme conditions, reducing downtime and maintenance costs.

    The inclusion of a versatile communication interface allows for easy connectivity to various devices within the factory floor, streamlining data exchange and control strategies.

    Crafted from durable materials, the module withstands harsh environmental conditions without compromising performance, offering a long service life and minimal wear and tear.

    User-friendly installation and configuration processes make it accessible to technicians and engineers alike, facilitating quick deployment and minimizing setup time.
