Allen Bradley 1746-OV16 16-Channel DC Output Module – Advanced Control in Industrial Automation

Product Type:Discrete output module

Series:SLC 500

Module Type:Digital DC Output

Nominal Input Voltage:24VDC

Input Voltage Range:10-50 VDC

Backplane current consumption:0.270 A

Voltage Range:10-50 Volts DC

Sink Outputs:16

On-State Voltage Drop:1.2 V

Off-State Output Leakage:1 MA

Load:1 MA

Current Rating:{“Backplane”:”0.28 A”,”Continuous Current Per Output”:”0.25 A at 60°C”,”Continuous Current Per Module”:”4 A at 60°C”}

Isolation:{“Communication Circuits”:”500 VDC”,”Backplane”:”1500 VAC”}

Processor:SLC 500

Enclosure:Open Type

Mounting:Chassis

Temperature Rating:0 – 60°C

Environmental Conditions:5 – 95%

    Engineered for durability and reliability, the Allen Bradley 1746-OV16 module is designed to withstand the harsh conditions often found in industrial environments, ensuring consistent performance over time.

    Featuring a compact footprint and high-density channel configuration, this module optimizes space and resource utilization on your control panel, making it an ideal choice for complex automation systems.

    With its 16-channel capability, the 1746-OV16 allows for fine-grained control over actuators, sensors, and other devices in your industrial setup, enhancing operational efficiency and precision.

    The module supports both 24VDC input and output voltages, offering flexibility in interfacing with various components and systems within your network.

    Equipped with advanced isolation features, it ensures reliable data transmission without interference, safeguarding your system’s integrity and enhancing safety standards.
