Allen Bradley 1746-NO4V Output Module, SLC 500 Series

Number of Channels:4

Output Type:Digital DC

Output Voltage Range:10 – 50 VDC

On-State Voltage Drop:1.2 V

Off-State Output Leakage:1 MA

Load Capacity:1 MA per channel

Current Rating per Output:0.25 A at 60°C

Continuous Current per Module:4 A at 60°C

Isolation:500 VDC for communication circuits, 1500 VAC for backplane

Temperature Range:-40°C to +85°C

Operating Voltage:24 VDC

Mounting:Chassis

Enclosure Type:Open Type

Communication Compatibility:Supports ControlNet, DeviceNet, EtherNet/IP

    Experience unparalleled precision and reliability with the Allen Bradley 1746-NO4V SLC 500 Output Module. This cutting-edge digital output device is engineered to deliver exceptional performance in even the most demanding industrial environments.

    Featuring four (4) high-performance channels capable of delivering voltage outputs from 10 to 50 volts DC, this module ensures efficient control over machinery and processes.

    With an on-state voltage drop of just 1.2 volts and a leakage current of 1 milliampere, the 1746-NO4V guarantees minimal power consumption and reduced heat generation, enhancing system efficiency.

    Designed for easy integration into existing control systems, this module supports seamless communication through its robust isolation capabilities, ensuring uninterrupted operation in noisy industrial settings.

    Engineered for durability and longevity, the open-type enclosure protects the internal components from dust, moisture, and other environmental hazards, making it suitable for outdoor and harsh industrial use.

    Backed by Allen Bradley’s commitment to quality and innovation, the 1746-NO4V is an ideal choice for automating complex operations, enhancing production throughput, and achieving optimal performance in your industrial applications.
