Allen Bradley 1746-IG16 SLC 500 Digital Input Module – Industrial Automation Innovation

Number of Inputs:16

Common Mode Voltage Range:-20 To 20 V

Absolute Input Voltage:+/- 7.5 VDC or 7.5 VAC RMS (Maximum)

Input Range (-20 To 20 MA):-10 To 10 VDC – 1 LSB

Overvoltage Protection:7.5 VAC RMS

Backplane Current Draw:35 MA at 5 V, 85 MA at 24 V

Isolation:Backplane: 500 VDC

Enclosure:Open Type

Temperature Rating:0 – 60 DEG C

Environmental Conditions:5 – 95%

Mounting:Chassis

    Integrating seamlessly into Allen Bradley’s renowned SLC 500 system, the 1746-IG16 Digital Input Module offers unparalleled reliability and precision in industrial control environments.

    Featuring a robust design capable of handling a wide range of voltage and current inputs, this module ensures accurate signal detection and processing under various operational conditions.

    With its high-resolution input capability, it provides enhanced sensitivity, making it ideal for applications requiring precise control over processes or equipment.

    Engineered with advanced isolation technology, the module ensures electromagnetic compatibility and protects against potential interference, guaranteeing stable operation even in harsh industrial settings.

    Simple installation and user-friendly configuration make it accessible to technicians and engineers alike, facilitating quick integration into existing systems without compromising performance.
