P+F KFD2-UT2-EX1 Extended Temperature Converter, Industrial Automation Solutions

Product Type:Temperature Converter Module

Power Supply:24 V DC (Power Rail)

Input Types:Thermocouple, RTD, Potentiometer, Voltage

Output Type:Current Output (0/4 mA to 20 mA)

Output Mode:Sink or Source

Configurability:Via PACTware

Line Fault Detection:LFD

Sensor Burnout Detection:Enabled

Safety Rating:Up to SIL 2 acc. to IEC 61508/IEC 61511

Rated Voltage:20 to 30 V DC

Connection:Screw Terminals

Mounting:On 35 mm DIN Rail

Mass:Approx. 130 g

Dimensions:20 x 119 x 115 mm

    The Pepperl+Fuchs KFD2-UT2-EX1 is designed with an integrated 1-channel isolated barrier, ensuring high-level signal isolation and protection against external electrical disturbances.

    Featuring a compact and robust design, this universal temperature converter offers a versatile solution for various industrial environments, supporting diverse input types including thermocouples, resistance temperature detectors (RTDs), potentiometers, and voltage inputs.

    With configurable options accessible through PACTware, users can tailor the device’s performance to meet specific application requirements, enhancing system flexibility and efficiency.

    The device includes advanced fault detection capabilities, including line fault (LFD) and sensor burnout detection, which helps maintain operational integrity and safety in critical control systems.

    Certified up to SIL 2 according to IEC 61508/IEC 61511, the KFD2-UT2-EX1 meets stringent safety standards for functional safety applications, ensuring reliable performance in hazardous environments.

    Compact yet powerful, this temperature converter seamlessly integrates into existing control systems, offering enhanced accuracy and reliability for a wide array of industrial applications.
