Opto 22 SNAP-AITM-2 Analog Input Module

Manufacturer:Opto 22

Model:SNAP-AITM-2

Module Type:Analog Input Module

Input Channels:2 Channels

Input Voltage Range:0-10V DC

Resolution:16-bit

Sampling Rate:Up to 10 kHz per channel

Terminal Block:Pluggable screw terminals

Operating Temperature Range:-40°C to 85°C

Power Supply:12-24 VDC

Weight:0.2 kg

Dimensions:3.81 cm x 9.53 cm x 8.89 cm

    The OPTO 22 SNAP-AITM-2 is a high-performance analog input module specifically designed for industrial applications. This module features two channels for precise voltage and current measurements, making it perfect for environments where accuracy and reliability are critical. With a sampling rate of up to 100 samples per second, the SNAP-AITM-2 ensures real-time monitoring and data acquisition. The module supports a wide nominal input voltage range of 0-10 VDC and input current range of 0-20 mA, providing flexibility in various industrial settings. Its robust design allows it to operate within a temperature range from -20°C to +70°C, ensuring stable performance even in harsh environments. Additionally, the module is compact and lightweight, with dimensions of 3.7 x 3.7 x 2.2 cm and a weight of only 0.04 kg, making it easy to integrate into existing systems. The SNAP-AITM-2 is built with precision engineering and high-quality components, guaranteeing long-term durability and reliable operation. Whether you need to monitor process variables or control industrial processes, the OPTO 22 SNAP-AITM-2 delivers exceptional performance and value.
