OMRON CP1W Analog Input Module – TS002, Advanced Control Solutions for Industrial Automation

Number of Input Ports:4

Input Current (Typical):5 mA @ 24 VDC

Rated Voltage:24 VDC (20.4 to 28.8 VDC)

Leakage Current:Max 0.1 mA

Internal I/O Common:PNP

Signal Range:Platinum Resistance (Pt100)

Conversion Speed:250 ms/8 inputs

Size (HxWxD):90 x 86 x 50 mm

    The OMRON CP1W-TS002 Analog Input Module is engineered for high-precision data acquisition in industrial settings, ensuring reliable performance under demanding conditions. With 4 thermocouple input points, it excels in temperature sensing applications, providing critical feedback for process control.

    DIN rail mounting facilitates easy installation, enhancing efficiency and reducing setup time in factory layouts. Its compact size (90 x 86 x 50 mm) allows for space optimization, making it suitable for both new and retrofit projects.

    This module supports PNP internal I/O commoning, enabling flexible connection options that cater to various industrial control scenarios. The rated voltage of 24 VDC (with tolerance between 20.4 to 28.8 VDC) ensures compatibility with a wide range of power sources, guaranteeing operational safety and reliability.

    Featuring a leakage current limit of 0.1 mA maximum, the CP1W-TS002 ensures minimal power consumption, contributing to energy-efficient operations. This makes it an ideal choice for energy-conscious manufacturing processes seeking to optimize costs and environmental impact.

    For further assurance, the product complies with international standards including UL, CSA, cULus, NK, Lloyd’s, and CE Directives. This ensures its safe and effective use across different geographical locations and industries, providing peace of mind to global users.
