Infineon BSM35GD120DN2 IGBT Module for High-Performance Power Conversion

Rated Voltage:1200V

Rated Current:35A

Package Type:DIN Rail Mount

Cooling Method:Heat Sink

Switching Frequency:Up to 20kHz

Operating Temperature Range:-40°C to +150°C

Gate Drive Voltage:+/-15V

    This Infineon BSM35GD120DN2 IGBT Module is meticulously engineered for demanding industrial environments, where reliability and efficiency are paramount. Featuring a robust dual inline package, it offers superior thermal management capabilities, ensuring consistent performance even under extreme operating temperatures.

    Designed for seamless integration into existing systems, this module is built with the latest IGBT technology, delivering high efficiency and low losses. Its ability to switch at frequencies up to 20kHz makes it ideal for applications requiring precise control and rapid response times.

    The BSM35GD120DN2 is constructed with premium materials, providing excellent durability and long service life. Its compact size and lightweight design make installation and maintenance straightforward and cost-effective.

    Optimized for use in industrial control systems, this IGBT module supports a wide operating temperature range from -55°C to +150°C, making it suitable for a variety of harsh environments. The low thermal resistance ensures efficient heat dissipation, further enhancing overall system reliability.

    To ensure ease of use and optimal performance, detailed installation guidelines and user manuals are provided. These resources include step-by-step instructions for proper handling and installation, helping users achieve the best results with minimal downtime.
