GE SR745-W2-P5-G1-HIE - Advanced Transformer Protection System

GE SR745-W2-P5-G1-HIE – Advanced Transformer Protection System

In stock

The GE SR745-W2-P5-G1-HIE is an advanced transformer protection system designed to safeguard transformers, autotransformers, and reactors from potential faults and damages. With its robust design and comprehensive monitoring capabilities, it ensures reliable operation in industrial environments.

Windings Per Phase:2

Resistant Temperature Device (RTD) Type:3-wire; 100 Ω Nickel, 120 Ω Nickel, 100 Ω Platinum

Analog Output Maximum Load:10 kΩ at 0 to 1 mA, 600 Ω at 4 to 20 mA

Maximum Continuous Voltage Output:273 V

Display Type:40-character Enhanced LCD

Dimensions:9”H, 7 ⅛”D, 7”W

Control Power Range:90 to 300 V DC; 70 to 265 V AC at 48 to 62 Hz

The GE SR745-W2-P5-G1-HIE Industrial Transformer Protection System offers an enhanced 40-character display, providing a larger and more readable screen compared to the base model.

With an expanded keypad, manual entry of setpoints becomes more efficient and error-free.

Its compact design with dimensions of 9 inches in height, 7 inches in width, and 7.

125 inches in depth allows for easy installation on a standard 19-inch panel.

The front panel features multiple LEDs that indicate real-time status and error alerts, ensuring quick identification and response to any issues.

Built using a robust SR-series arrangement, the system includes a draw-out relay and a companion case, offering increased durability and reliability in the operational environment.

GE SR745-W2-P5-G1-HIE
