GE SR745-W2-P1-G1-HI-E-H, Industrial Transformer Management System

In stock

The GE SR745-W2-P1-G1-HI-E-H is an advanced transformer protection system designed to monitor and safeguard transformers, autotransformers, and reactors. It offers an enhanced 40-character display and an expanded keypad for easier manual entry of setpoints.

Winding Configuration:2 windings per phase

Resistant Temperature Device (RTD):Type 3 wire; 100 Ω Nickel, 120 Ω Nickel, 100 Ω Platinum

Analog Output Maximum Load:10 kΩ at 0 to 1 mA, 600 Ω at 4 to 20 mA

Maximum Continuous Voltage Output:273 V

Display Type:40-character Enhanced LCD

Dimensions:9”H x 7”W x 7 ⅛”D

Control Power Range:90 to 300 V DC; 70 to 265 V AC at 48 to 62 Hz

The GE SR745-W2-P1-G1-HI-E-H is a robust and reliable solution for managing and protecting transformers, autotransformers, and reactors.

With its advanced 40-character display and expanded keypad, this system allows for easy and precise manual entry of setpoints.

The case dimensions are 9 inches high, 7 inches wide, and 7 ⅛ inches deep, making it compact yet sturdy.

The transformer protection system can be conveniently mounted on a standard 19″ panel, ensuring a secure installation.

The front of the case features multiple LEDs that provide real-time alerts for various statuses and errors, allowing operators to quickly identify and address any issues.

Designed with safety and efficiency in mind, the GE SR745-W2-P1-G1-HI-E-H ensures seamless operation and optimal performance in demanding industrial environments.
