GE SR469 469-P5-H1-A20-E Generator Management Relay

Protection Type:Motor Management Relay

Model Number:469-P5-H1-A20-E

Brand:General Electric (GE)

Input Capacity:Multiple RTD inputs

Temperature Determination:Actual temperature and hottest point

Wire Composition:Three-wire system: 100 ohm Nickel, 120 ohm Nickel, 10 ohm Copper, 100 ohm Platinum

Current Monitoring Range:Programmable up to 19,200 baud

Enclosure Rating:20-X

Frequency Compatibility:48-62Hz

Phase CT:5A

Voltage Ratings:90-300VDC, 70-265VAC

Overvoltage Category:II

Insulation Voltage:300V

Pollution Degree:2

Output Channels:4 Analog

RS-232 Interface:9600 baud, programmable up to 19,200 baud

    The GE SR469 469-P5-H1-A20-E boasts a compact yet robust design tailored for demanding industrial environments. Its advanced technology ensures precise monitoring and control, significantly enhancing operational efficiency and safety.

    This generator management relay incorporates multiple RTD inputs for accurate temperature measurement, pinpointing the hottest point in your motor system. The precision-engineered RTDs, made from 100 ohm Nickel, 120 ohm Nickel, 10 ohm Copper, and 100 ohm Platinum, guarantee reliable and consistent performance.

    With its enhanced front panel, the SR469-P5-H1-A20-E offers a user-friendly interface equipped with an RS-232 program port for easy configuration. The programmable baud rate allows for seamless integration with various systems, maximizing compatibility and functionality.

    Equipped with a draw-out handle that can be sealed, this relay provides an added layer of security against unauthorized access or tampering, ensuring the integrity and safety of your operations. It is rated for 20-X enclosure, suitable for a wide range of environmental conditions.

    Designed for motor management, the GE SR469 469-P5-H1-A20-E excels in overvoltage protection, offering unparalleled reliability and efficiency. Its comprehensive specifications and cutting-edge features make it an indispensable component in modern industrial applications, delivering exceptional value and performance.
