GE DS3800DMEA1D1C Printed Circuit Board - Industrial Control Module

GE DS3800DMEA1D1C Printed Circuit Board – Industrial Control Module

In stock

The DS3800DMEA1D1C is a printed circuit board designed by GE for gas turbine control applications. It facilitates critical functions such as air, fuel, and emission controls, generator synchronization, and system voltage matching. Additionally, it offers protection mechanisms against adverse operating conditions.

Board Type:Printed Circuit Board

Manufacturer:General Electric

Model:DS3800DMEA1D1C

Mounting Holes:Five mounting holes, one in each corner and two additional holes in the top left and bottom left corners

Terminals:Eight screw terminals

Diodes:Eight diodes

Resistors:21 ceramic, metal film resistors

LEDs:Eight labeled LEDs for status indication

Switches:One switch (labeled SW1)

The DS3800DMEA1D1C board is meticulously engineered to provide critical functions in gas turbine systems, including air, fuel, and emissions control, synchronization and voltage matching of the generator with the system, and protection mechanisms against adverse operating conditions.

Constructed with robust materials, it ensures reliable performance under demanding industrial environments.

Its eight screw terminals and diodes facilitate efficient electrical connections, while the twenty-one ceramic, metal film resistors contribute to precise regulation.

With a switch labeled SW1 and eight LED indicators, the board offers clear operational feedback.

Mounting is facilitated by five drilled holes strategically placed for secure attachment.

The DS3800DMEA1D1C is not just a component; it’s a testament to GE’s commitment to excellence in industrial control solutions.
