GE 745-W3-P5-G5-HI-A-L-R-E-H: Advanced Transformer Protection Relay

In stock

The GE 745-W3-P5-G5-HI-A-L-R-E-H is a sophisticated transformer management relay designed to optimize performance and enhance safety in industrial control systems. It efficiently monitors and controls transformers in a variety of applications, ensuring reliable operation and minimal downtime.

Operating Environment:Humidity up to 90% non-condensing

Weight:4.8kg

Voltage Relay Input:60 to 120 V

Relay Dimensions:9”H, 7 ⅛”D, 7”W

Overload Withstand:1 second at 80 times rated current, continuous at 3 times rated current

Ground Current Relay Input:5 A

Display Type:40 character LCD

Windings Per Phase:Three

Control Power:90 to 300 VDC; 70 to 265 VAC at 48 to 62 Hz

Analog Input/Output:Included

Loss of Life:Included

Restricted Ground Fault:Included

FlexLogic™ Technology:Equation format allowing up to 20 parameters for protecting and monitoring inputs and outputs

The GE 745-W3-P5-G5-HI-A-L-R-E-H is an advanced transformer management relay that seamlessly integrates with industrial control systems. Its compact design ensures efficient space utilization on the control panel without compromising functionality.

This relay boasts a versatile display type, featuring a 40 character Enhanced LCD screen that provides clear, readable information under various lighting conditions. The display facilitates easy monitoring of transformer parameters, enhancing operational efficiency.

With its robust overload withstand capability, the GE 745-W3-P5-G5-HI-A-L-R-E-H can handle up to 1 second at 80 times rated current, and maintain continuous operation at 3 times rated current. This feature ensures the relay remains functional even under severe operational stress.

The use of a .5 × 20 mm slow-blow Littelfuse fuse type ensures that the relay can safely interrupt the circuit in the event of a fault, minimizing damage to the transformer and preventing potential hazards. The DC mA analog input type allows for precise measurement of current, providing critical data for effective control and monitoring.

Designed with user-friendliness in mind, the GE 745-W3-P5-G5-HI-A-L-R-E-H comes equipped with a detailed manual and online support resources. These resources guide users through setup, configuration, and troubleshooting, ensuring smooth integration and optimal performance in real-world applications.
