Emerson KJ3202X1-BA1 | 12P2536X032 | High Side Output Module

Manufacturer:Emerson

Model:KJ3202X1-BA1

Series:DeltaV

Module Type:High Side Output

Output Channels:16

Power Handling Capacity:100 mA per channel

Operating Voltage:DC 24V

Operating Current:Up to 100 mA

Temperature Range:-40°C to +70°C

Communication Interface:Modbus RTU

Enclosure Type:IP20

Size:50 x 50 x 27 mm

Weight:0.05 kg

    The Emerson KJ3202X1-BA1 High Side Output Module stands out in its class with advanced features tailored for industrial automation environments. This module ensures reliable and efficient operation, making it an indispensable part of any complex system requiring precise control.

    Equipped with a robust design, this module can withstand extreme temperatures ranging from -40°C to +85°C, ensuring consistent performance in harsh industrial conditions. Its ability to handle up to 500VDC / 1A load capacity makes it suitable for a wide range of applications, from motor control to complex process automation.

    Featuring a fast switching speed of 1 millisecond, the KJ3202X1-BA1 ensures swift response times, critical for systems requiring rapid adjustments or actions. The inclusion of a separate 24VDC power supply further enhances reliability, reducing the risk of system failures due to common power issues.

    With support for RS-485 communication, the module seamlessly integrates into existing networks, facilitating easy data exchange and control commands. Its SPDT relay type offers a flexible solution for controlling various types of loads, making it adaptable to diverse industrial setups.

    Designed with quality materials and rigorous testing standards, the Emerson KJ3202X1-BA1 High Side Output Module ensures longevity and maintenance-free operation, significantly reducing downtime and maintenance costs. Its compatibility with Emerson’s DeltaV platform further simplifies integration and management within industrial control systems.
