ABB AO801 – 3BSE020514R1 Analog Output Module

Manufacturer:ABB

Model Number:AO801 3BSE020514R1

Module Type:Analog Output

Current Rating:10mA

Voltage Range:0-10VDC / 4-20mA

Communication Protocol:Modbus RTU

Environmental Rating:IP20

Operating Temperature:-25°C to +60°C

Mounting:Panel Mount

Power Consumption:Max. 50mW

Dimensions:15.2mm x 50mm x 89mm

    Introducing the ABB AO801 3BSE020514R1 Analog Output Module, a critical component for advanced industrial control systems. This module ensures precise analog signal output, crucial for processes requiring high accuracy and reliability. With its robust design and compatibility with a wide range of communication protocols, it seamlessly integrates into various industrial automation setups, enhancing operational efficiency and reducing downtime.

    Featuring 1-channel capability, this module supports current ranges from 0 to 20 mA and voltage ranges from 0 to 10 V, providing versatile control options for diverse applications. The inclusion of Modbus RTU protocol ensures compatibility with existing systems and facilitates easy setup and configuration.

    Operational excellence is ensured with an operating temperature range of -25°C to +60°C and a humidity tolerance of 5% to 95% RH, making it suitable for a broad range of industrial environments. Its DC 24V power supply ensures stable performance, even under varying conditions.

    Compact yet powerful, the module measures 84 x 131 x 91 mm and weighs only 0.3 kg, making it easy to install and manage within tight space constraints. The built-in isolation rating of 1000 V AC further enhances safety and reduces interference, ensuring reliable operation in harsh industrial settings.

    Designed for long-term durability and reliability, the ABB AO801 3BSE020514R1 Analog Output Module is an essential upgrade for any industrial control system aiming to improve precision, efficiency, and overall system performance.
