ABB 5SHX1445H0002 | High-Power IGCT Module

Power Rating:2500 kW

Operating Voltage:690 VAC

Current Rating:4400 A

Frequency Range:50 Hz to 60 Hz

Switching Speed:Less than 10 μs

Insulation Class:F-Class Insulation

Cooling Method:Air Cooled

Dimensions:385 mm x 175 mm x 190 mm

Weight:18 kg

    Engineered for unparalleled performance in industrial control systems, the ABB 5SHX1445H0002 IGCT module boasts a high operating voltage of up to 5kV, capable of delivering a maximum current of 1445A under optimal conditions.

    This module is designed to operate at frequencies up to 10kHz, providing flexibility for various applications requiring precise control and high-speed switching.

    The integrated thermal design ensures efficient heat dissipation, maximizing the module’s lifespan and reliability even in the most challenging environments.

    Equipped with an insulation resistance of 100MΩ at 500V DC, the ABB 5SHX1445H0002 offers enhanced safety and reliability, ensuring seamless operation in industrial circuits.

    Featuring an IP54 environmental sealing rating, this IGCT module is protected against dust ingress and splashing water, making it suitable for use in outdoor or harsh industrial settings without compromising performance.
