AB MVI56-MCMR Industrial Module for ControlLogix Systems

Backward Compatibility:Compatible with previous MVI56-MCMR versions

Slot Type:Single Slot

ControlLogix Backplane:1756 ControlLogix® backplane compatible

Ethernet Port Speed:10/100 MB Ethernet port

Auto Cable Crossover Detection:Yes

Data Memory Mapping:User-definable module data memory mapping of up to 5000 16-bit registers

Network Diagnostics:CIPconnect®-enabled network configuration and diagnostics monitoring using ControlLogix 1756-ENxT and 1756-CNB modules

Pass-Through Communication:EtherNet/IP pass-through communication

    The AB MVI56-MCMR Module is designed to bridge across multiple ENBT/CNBT links, enabling connection to MVI56E-MCMRs installed in remote chassis for configuration and diagnostics. It features a 4-digit LED display for quick viewing of critical configuration and status information without the need to connect directly to the ports. The module is backward-compatible with previous versions, ensuring it can integrate smoothly into existing systems.

    Its single-slot design makes it ideal for installations within a 1756 ControlLogix® backplane, providing seamless integration. The 10/100 MB Ethernet port supports auto cable crossover detection, simplifying setup and reducing installation time. With user-definable module data memory mapping capabilities of up to 5000 16-bit registers, this module offers extensive customization options to meet specific application needs.

    CIPconnect®-enabled network configuration and diagnostics monitoring using ControlLogix further enhance its functionality, allowing for efficient management and troubleshooting of remote racks. Additionally, the reduced I/O image size is specially designed to optimize remote rack implementations, improving system performance and reliability.
